Weight : 240 g
Color : White
Size : 109mm×85.5mm
No_Of_Piece_Per_Box : 1
Series : S & A Distribution
Voltage : 12V DC
Video Recording Resolution : 2MP
Video Recording Frame Rate : 20fps
Protocol : HTTP;TCP;ARP;RTSP;RTP;RTCP;UDP;DHCP;DNS;IPV4;NTP;Multicas; ICMP; TLS; ONVIF Profile S&G
WDR : DWDR
IP Rating : IP67
Image Sensor :1/2.7" 2MP PS CMOS Image Sensor
Minimum Illumination : 0.09Lux/F2.0(Color,1/3s,30IRE) 0.5Lux/F2.0(Color,1/30s,30IRE) 0Lux/F2.0(IR on)
Effective Pixels : 1920(H)x1080(V)
White Balance : Auto/Natural/Street Lamp/Outdoor/Manual
Lens: 2.8mm fixed lens (3.6mm optional)
Gain Control (AGC) : Auto/Manual
Video Compression : H.265+/H.265/H.264+/H.264H/MJPEG(Sub Stream)
Angle of View : H:115degree/87.5degree,V:60degree/47degree S/N RatioMore than 50dB
Back Light Comp. :BLC/ HLC/ DWDR Frame RateMain Stream: 1080P (1 ~ 20fps) ,Sub Stream: D1(1 ~ 25/30fps) Digital Zoom16x
Resolution: 1080P(1920×1080)/1.3MP(1280×960)/ 720P(1280×720)/D1(704×576/704×480)/ VGA(640×480)/ CIF(352×288/352×240)
Motion Detection :Off / On (4 Zone,Rectangle)
Privacy Mask : Off / On (4 Area,Rectangle)
ICR : Auto(ICR)/Color/B/W ROIOff / On (4 Zone)
Audio :No
WDR : No
Bit Rate :H265: 12K~5632K ,H.264: 32K ~8192K
IVS : No
Ethernet : RJ-45 (10/100Base-T)
User Account: 20 Users
Smart Phone : iPhone,iPad,Android Phone
IR Range: IR Range of 30 Mtr.
SD Card :No
Operating Temperature :-30degreeC~+60degreeC ,Less than 95%RH
Power Source :DC12V,PoE (802.3af)
Power Source : DC12V,PoE (802.3af)
Power Consumption :<4.8W
Weatherproof Standard : IP67
