Weight : 5800 g
Color : White
Size : 209x337.4mm
No_of_piece_per_box : 1
Series : Pro Series
Voltage : AC24V/3A(±25%)
Video Recording Resolution : 2MP
Protocol : IPv4/IPv6,HTTP,HTTPS,SSL,TCP/IP,UDP,UPnP,ICMP,IGMP,SNMP,RTSP,RTP,SMTP,NTP,DHCP,DNS,PPPOE,DDNS,FTP,IP Filter,QoS,Bonjour,802.1x,ONVIF Profile S&G,API
Image Sensor: 1/2.8" PS CMOS
Effective Pixels: 1920(H) x 1080(V),2 Megapixels
Resolution: 2MP
Video Output: 1 Port
S/N Ratio: More than 55dB
Minimum Illumination: Color: [email protected];B/W: [email protected]; [email protected] (IR on)
Focal Length: 3.95mm~177.7mm
White Balance: Auto,ATW,Indoor,Outdoor,Manual
Focus Control: Auto / Manual Close
Focus Distance: 100mm~ 1000mm
Angle of View: H: 70.3degree ~ 1.8degree
Electronic Shutter: 1/1s~1/30,000s
AGC Control: Auto / Manual
Back Light Compensation : BLC / HLC / WDR(120dB)
Optical Zoom : 45x
Digital Zoom : 16x
Pan Travel: 0degree~360degree endless,Pan Speed: 0.1degree ~200degree /s
Tilt Travel: -20degree ~ 90degree,auto flip 180degree,Tilt Speed: 0.1degree ~120degree/sec
Manual Speed: Pan: 0.1degree ~200degree /s; Tilt: 0.1degree ~120degree /s
Presets: 300
Preset Speed: Pan: 300degree /s; Tilt: 200degree /s
Special Features: Defog,EIS,IR Range upto 250mtr,Up to 300 Presets,5 Pattern,8 Tour,Auto Pan ,Auto Scan
Privacy Mask: Up to 24 areas
Power up Action: Auto restore to previous PTZ and lens status after power failure
Idle Motion: Activate Preset/ Scan/ Tour/ Pattern if there is no command in the specified period
Day/Night: IR Cut Filter: Auto(ICR) / Color / B/W
Video Compression : H.265+/H.265/H.264+/H.264
Video Streaming: Main stream: 1080P/1.3M/720P(1~50/60fps),Sub stream1: D1/CIF(1 ~ 25/30fps),Sub stream2: 1080P/1.3M/720P/D1/CIF (1~25/30fps)
Motion Detection: Supports
ROI: Supports
Audio Streaming: 1/1 channel In/Out
Auto Tracking: Supports
Auto tracking: Yes
Networking: RJ-45 (10Base-T/100Base-TX) ,1 RS485
IVS: Tripwire,Intrusion,Abandoned/Missing,Face Detection,Heat Map
IVS: Yes
Alarm: 7/2 channel In/Out
Tracking Trigger : EventMotion detection,Video tampering ,Scene changing,Network disconnection,IP address conflict,Illegal Access,Storage anomaly
IR Range: 250 Mtr.
Operating Temperature: -40degreeC ~ 70degreeC / Less than 95% RH
Smart Phone: iPhone,iPad,Android Phone
Memory Slot: Micro SD card 256GB
Weatherproof Standard: IP67 & IK10
Dimension: φ209 x 337.4mm
Weight: 5.8kg
Power Source: AC24V/3A(±25%),PoE+(802.3at)
Power Consumption : 17W,25W(IR On,Heater On)
