Brand: Philips
Product Code: 913713937249
Product Name: 100mA 40A Double Pole RCCB

Technical Specifications
Color: Grey
Material: Metal/plastic
Current Rate: 40A
Philips SafeTec RCCB - For AC applications of 16-63A
Product Range: SafeTec
Minimum Installation Box Depth: 10 cm
Product dimensions: Length 9.29 cm x Width 7.344 cm x Depth 3.56 cm
Connection Terminals: Saddle
Power
Electrical Load Type: Resistive load
Power consumption
Voltage: 240 V
Miscellaneous
Approval Marks: BIS Certificate

Other characteristics
Installation Type: Din Rail
Trip Unit Technology: Electro- Mechanical
Class of protection: Class III
Number of Poles: 2 Pole
Earth Leakage Sensitivity: 100 mA
Electrical Insulation Class: Class III
Energy: Limitation Class: Class III
Shorttime Withstand Current: 40-40 A
Frequency: 50 Hz

Overview
Pad lock facility
Pad Locking option available so that dolly can be locked in OFF condition during maintenance to avoid any accident.
Description window
Description window with label to identify the connection, Convenance to use during installation and maintenance.
Air circulation
Designed with Air channels which provide better air circulation around individual poles.
This improves the thermal situation and thus improves the life of the product.
FR grade material
FR Grade material is used while making the circuit breaker so that it detracts accidental fires.
Sensitivity Range
With different sensitivity of leakage current to protect from shocks.
Efficient heat management
Air vent provided for better heat management and longer life.
High short circuit withstand capacity
Can withstand 6kA short circuit breaking capacity.
Snap locks
Plastic body fitted with snap lock this helps in easy to lock and unblock.
Gloss finish
Glossy white finish which flushes with the wall and also easy to clean.
